Alloy Fasteners

Alloy Material

ERNiCrMo-3

Quantity:
It is used for welding nickel-chromium-molybdenum alloy (ASTM B 443, B 444, and B 446 having UNS number N06625) to itself, to steel, to other nickel-base alloys, for cladding steel with nickel-chromium molybdenum weld metal, and for welding the clad side of joints in steel with nickel-chromium-molybdenum alloy using the GTAW, GMAW, SAW, and PAW processes. This filler metal is recommended for applications where the operating temperature ranges from cryogenic to 1000°F [540°C].


Available Product Forms

ERNiCrMo-3 is available on spool (Precision Layer Wound) and in cut straight lengths. We have controlled cast and helix for MIG wires.
Available in Diameters Length
Straight Rods(TIG)-inch .047 .062 .093 .125 36 or 39
Straight Rods(TIG)-mm 1.2 1.6 2.4 3.2 915 or 1000
Spooled Wire (MIG)-inch .030 .035 .040 .045 Spool
Spooled Wire (MIG)-mm 0.8 0.9 1.0 1.14 Spool

ERNiCrMo-3 Chemical Composition:
Grade Ni% C%* Mn% Fe%* S% Cu% Si% Al% Cr% Ti% Nb% Mo% P%
ERNiCrMo-3 Min 64 Max 0.1 Max 0.5 Max 1.0 Max 0.015 Max 0.50 Max 0.50 Max 0.40 22.0-23.0 Max 0.40 3.6-4.5 9.2-10.0 Max 0.015

Specifications
Grade American European
ERNiCrMo-3 AWS A5.14, ERNiCrMo-3*
ASME II, SFA-5.14, ERNiCrMo-3
ASME IX, F-No. 43
UNS N06625
BS 2901 (NA43)
DIN 1736 SG-NiCr21Mo9Nb
Werkstoff Nr. 2.4831
Europe NiCr22Mo9Nb

*ERNiCrMo-3 is manufactured by NiWire Industries under AWS A5.14.
