Features:
UNS Number N07718
Inconel 718 is an age-hardenable nickel-chromium alloy that combines corrosion resistance with high strength and good fabricability. It has a high creep-rupture strength at temperatures up to 700℃. Its excellent relaxation resistance contributes to its application in springs.
Applications:
Inconel 718 is applied in Gas turbine engines, rocket motors, nuclear reactors and spacecraft, etc.
Forms of Inconel 718 Available at China Special Bolts
• Sheet
• Plate
• Bar
• Wire
Inconel 718 Chemical composition:
| Alloy | % | Ni | Cr | Fe | Mo | Nb | Co | C | Mn | Si | S | Cu | Al | Ti |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 718 | Min. | 50 | 17 | balance | 2.8 | 4.75 | 0.2 | 0.7 | ||||||
| Max. | 55 | 21 | 3.3 | 5.5 | 1 | 0.08 | 0.35 | 0.35 | 0.01 | 0.3 | 0.8 | 1.15 |
Inconel 718 Physical properties:
| Density | 8.2 g/cm³ |
| Melting point | 1260-1340 ℃ |
Inconel 718 Alloy minimum mechanical properties in the roomtemperature:
| Alloy | Tensile strength Rm N/mm² | Yield strength R P0. 2N/mm² | Elongation A 5 % | Brinell hardness HB |
| Solution treatment | 965 | 550 | 30 | ≤363 |
ASTM Specifications
| Sheet/Plate | Bar |
|---|---|
| B670 | B637 |
