Nimonic 80A

Availability:
Quantity:

Characteristic as below:
A nickel-chromium alloy similar to NIMONIC alloy 75 but made precipitation hardenable by additions of aluminum and titanium. The alloy has good corrosion and oxidation resistance and high tensile and creep-rupture properties at temperatures to 1500℉(815℃). Used for gas-turbine components (blades, rings, and discs), bolts, tube supports in nuclear steam generators, die-casting inserts and cores, and exhaust valves in internal-combustion engines.


Nimonic 80A (UNS N07080)
Nimonic 80A Chemaical composition:

Alloy % Ni Cr Fe Mn Si P S Al Ti C Co B Zr Cu
625 Min. Balance 18




1.0 1.8




Max.
21 3.0 1.0 1.0 0.02 0.015 1.8 2.7 0.1 2.0 0.008 0.15 0.2


Nimonic 80A Physical properties:

Density 8.19 g/cm3
Melting range 1320-1365℃


Nimonic 80A minimum mechanical properties in the room temperature:

Status Tensile strength
Rm N/mm2
Yield strength RP0.2N/mm2 Elongation A5 %
Nimonic 80A 930 620 20
